P250F Dual Row 04 to 80 Contacts Right Angle Type

P250F Dual  Row 04  to 80  Contacts  Right Angle Type

0.1" (2.54mm) Pin Header
Dual  Row 04  to 80  Contacts  Right Angle Type Profile:2.5mm

Specification
Current Rating:                        3.0 Amp
Insulator Resistance:            1000 M ohm min.
Contact Resistance:              20m ohm Max.
Dielectric Withstanding:       500 V AC/Min.
Operating Temperature:      -40℃ ~ +105℃
Max Processing Temp:        230℃ For 30~60 Seconds
                                          260℃ For 10 Seconds
Contact Material:                    Brass
Insulator Material:                  Polyester, UL 94V-0
                                                    Standard : Nylon-6T
Contact Plated:                       Full Gold, Full Tin,Selective Plated
